E5071C
258
Line/Match
1. Click Line/Match.
2. Click softkey to execute Line/Match calibration.
Softkey Function
x-y
Line/Match
Executes line/match calibration for test ports x and y.
Use this to perform forward-direction measurement
and reverse-direction measurement at the same time.
This is equivalent to measuring both x-y Fwd (Syx) and
x-y Rvs (Sxy).
x-y Fwd
(Syx)
Executes line/match calibration for test ports x and y.
Use this to perform forward-direction measurement
only.
x-y Rvs
(Sxy)
Executes line/match calibration for test ports x and y.
Use this to perform reverse-direction measurement
only.
3.
4. Click Return.
5. Click Done to finish TRL 2-port calibration. At this point, the
calibration coefficient is calculated and saved. The error correction
function is automatically turned on.
