E5071C
260
measurement only.
x-z
Line/Match
Executes line/match calibration for test ports x and
z. Use this to perform forward-direction
measurement and reverse-direction measurement
at the same time.
x-z Fwd
(Szx)
Executes line/match calibration for test ports x and
z. Use this to perform forward-direction
measurement only.
x-z Rvs
(Sxz)
Executes line/match calibration for test ports x and
z. Use this to perform reverse-direction
measurement only.
y-z
Line/Match
Executes line/match calibration for test ports y and
z. Use this to perform forward-direction
measurement and reverse-direction measurement
at the same time.
y-z Fwd
(Szy)
Executes line/match calibration for test ports y and
z. Use this to perform forward-direction
measurement only.
y-z Rvs
(Syz)
Executes line/match calibration for test ports y and
z. Use this to perform reverse-direction
measurement only.
8. Click Done to finish TRL 3-port calibration. At this point, the
calibration coefficient is calculated and saved. The error correction
function is automatically turned on.
