E5071C
2840
:DISPlay:ATRaces:SCALe:RPOSition
Type
Command/Query
Syntax
:DISPlay:ATRaces:SCALe:RPOSition {LEFT|CENTer}
:DISPlay:ATRaces:SCALe:RPOSition?
Description
This command sets x-axis reference position for the time domain
measurement.
Parameter
Description
Sets x-axis reference position for the time domain
measurement
Data Type Character string type (String)
Range
LEFT: The reference position is left edge
CENTer: The reference position is center
Preset
Value
LEFT
Unit -
Resolution -
Query Response
{LEFT|CENTer}<newline><^END>
Examples
10 OUTPUT 717;":DISP:ATR:SCAL:RPOS LEFT"
20 OUTPUT 717;":DISP:ATR:SCAL:RPOS?"
30 ENTER 717;A$
Equivalent GUI
TDR/TDT > or (Under Horizontal)
