E5071C
2848
:DISPlay:TRACe{Tr}:Y:SCALe:RLEVel
Type
Command/Query
Syntax
:DISPlay:TRACe{Tr}:Y:SCALe:RLEVel <numeric>
:DISPlay:TRACe{Tr}:Y:SCALe:RLEVel?
Description
This command sets value of y-axis reference line.
Parameter
Description Value at Y-axis reference line
Data Type Double precision floating point type (Double)
Range -
Preset Value 100
Unit -
Resolution -
Query Response
{numeric}<newline><^END>
Examples
10 OUTPUT 717;":DISP:TRAC1:Y:SCAL:RLEV 0.01"
20 OUTPUT 717;":DISP:TRAC1:Y:SCAL:RLEV?"
30 ENTER 717;A
Related Commands
:DISPlay:TRACe{Tr}:X:SCALe:RLEVel
Equivalent GUI
TDR/TDT > input box under the right knob (Under Vertical)
