E5071C
2852
MMEMORY
:MMEMory:LOAD:EYE:BPATtern
Type
Command Only
Syntax
:MMEMory:LOAD:EYE:BPATtern <string>
Description
This command loads the specified user bit pattern file. The extension of file
should be .txt. The bit pattern editing is not available through the
command.
Parameter
Description File name of user bit pattern (.txt)
Data Type Character string type (String)
Range -
Preset Value -
Unit -
Resolution -
Examples
10 OUTPUT 717;":MMEM:LOAD:EYE:BPAT ""D:\TDR\userbit.txt"""
20 OUTPUT 717;":CALC:EYE:INP:BPAT:TYPE USER"
Related Commands
:CALCulate:EYE:INPut:BPATtern:TYPE
Equivalent GUI
Eye/Mask > User Pattern (Under Bit Pattern) > Load
