E5071C
310
MAX
Segment at which the maximum is
specified
Begin Stimulus
Specify starting point for stimulus value on
the limit line
End Stimulus
Specify ending point for stimulus value on the
limit line
Begin Response
Specify starting point for response value on
the limit line
End Response
Specify ending point for response value on
the limit line
• The range in which stimulus values can be specified is from -
500 G to +500 G. When a value outside the range is entered, a
suitable value within the range is specified. Once the stimulus
value is specified, changing the sweep range of the E5071C
does not affect the stimulus value.
• The range in which response values can be specified is from -
500 M to +500 M. When a value outside this range is entered, a
suitable value within the range is specified. After the response
value is specified, changing formats results in changing the
units but not the value.
