E5071C
376
• You can set the auto port extension function channel by
channel. Setting the auto port extension function for one
particular channel does not affect other channels.
• When the sweep type is power sweep or the frequency offset
function is ON, the auto port extension is not available.
• Auto Port Extension does not supports waveguide port
extension.
1. Selecting a port(s)
Select the port(s) for which you want to use the auto port extension
function.
1. Press Channel Next/Channel Prev keys to activate the channel for
which you want to set auto port extension.
2. Press Cal key.
3. Click Port Extensions > Auto Port Extension > Select Ports to select
the port(s) for which you want to use the auto port extension
function.
2. Setting frequencies used for calculation
Set the frequency points with which you want to calculate a loss value.
1. Press Channel Next/Channel Prev keys to activate the channel to set
auto port extension.
2. Press Cal key.
3. Click Port Extensions > Auto Port Extension > Select Ports > Method
to set the frequencies used for calculation.
Softkey Function
Current
Span
Executed using the frequency range set currently.
Active
Marker
Executed using the frequency at the active marker.
In this case, the result is applied to Loss1. Loss2 is
ignored.
User Span
Executed using a start value and a stop value you
set.
