Agilent Technologies E5071C User Manual

E5071C
406
ECal type: Full 3-port calibration
3 Port
Test ports to be used for ECal: 1, 2, and 3
1, 2, 3
Select Channel
Channel on which ECal is to be executed: Channel 1
Channel: 1
6. Click Next. The EcalAssistant (connection) dialog box appears. Select
3-port/Channel:1.
Connecting the ECal module
