Measurement
435
By following 1-Port Calibration (reflection test), execute 1-port calibration
on port 1.
3. Connecting the DUT
Connect the DUT as shown below.
4. Auto Scale
Execute the auto scale function.
Setting Description Key Operation
Executing auto scale Scale > Auto Scale
