Measurement
475
Bal
Establishes port 1 on the DUT as balanced ports
4. Select each port on the analyzer to which a port on the DUT is
connected.
• When you have selected SE-Bal:
Softkey Function
Port 1
(se)
Selects a port on the analyzer from among 1, 2, 3,
and 4 for connection to logical 1 (Port a)
Port 2
(bal)
Selects two ports on the analyzer from among 1-2, 1-
3, 1-4, 2-1, 2-3, 2-4, 3-1, 3-2, 3-4, 4-1, 4-2, and 4-3 for
connection to logical port 2 (Port b and Port c)
• When you have selected Bal-Bal:
Softkey Function
Port 1
(bal)
Selects two ports on the analyzer from among 1-2, 1-
3, 1-4, 2-1, 2-3, 2-4, 3-1, 3-2, 3-4, 4-1, 4-2, and 4-3 for
connection to logical port 1 (Port a and Port b)
Port 2
(bal)
Selects two ports on the analyzer from among 1-2, 1-
3, 1-4, 2-1, 2-3, 2-4, 3-1, 3-2, 3-4, 4-1, 4-2, and 4-3 for
connection to logical port 2 (Port c and Port d)
• When you have selected SE-SE-Bal:
Softkey Function
Port 1
(se)
Selects a port on the analyzer from among 1, 2, 3, and
4 for connection to logical 1 (Port a)
Port 2
(se)
Selects a port on the analyzer from among 1, 2, 3, and
4 for connection to logical 2 (Port b)
Port 3
(bal)
Selects two ports on the analyzer from among 1-2, 1-3,
1-4, 2-1, 2-3, 2-4, 3-1, 3-2, 3-4, 4-1, 4-2, and 4-3 for
connection to logical port 3 (Port c and Port d)
• When you have selected Bal:
Softkey Function
To Next Page
