E5071C
482
Softkey Function
None
The matching circuit is not added.
Shunt L -
Shunt C
Selects a circuit model consisting of a shunt
inductor and a shunt capacitor
User
Selects the circuit model defined in the user file
imported in Step4.
7. Specify the values for the elements in the circuit model selected.
Softkey Function
C
Specifies the capacitance [F]
G
Specifies the conductance [S]
L
Specifies the inductance [H]
R
Specifies the resistance [Ω]
6.
o When either of the two components of Shunt-L, "L" and
"R", is set to 0, the component is defined as "Short";
when both components are set to 0, they are defined as
"Open."
7. Repeat the procedure to set up the differential matching circuit to be
added to the selected ports on the DUT.
8. Click Diff. Matching to turn the differential matching circuit ON.
9. Click Return.
10. If Fixture Simulator is OFF, press the key again to turn it ON.
