Product Information
855
B 7mm
N4431
A*
3.5 mm ECal** 85053B 300 kHz 9 GHz
N4431
B*
3.5 mm ECal** 85053B 9 kHz
13.5
GHz
N4431
A*
Type-N ECal** 85055A 300 kHz 9 GHz
N4431
B*
Type-N ECal** 85055A 9 kHz
13.5
GHz
The results from the verification kit other than following
combination are not warranted specification:
_______________________________________________________
__________________________________________
E5071C 3GHz, 4.5GHz, 6.5GHz, 8.5GHz (Option
230/235/240/245/260/265/280/285/430/435/440/445/460/465/
480/485)
Calibration Kit: 85032F, 85033E Electronic calibration (ECal)
module: 85092C, 85093C
____________________________________________________
____________________________________________________
______
E5071C 14GHz, 20GHz (Option 2D5/2K5/4D5/4K5)
Calibration Kit: 85052D
* The connection of the N4431x is for the thru path A-B,
C-D, A-D, and B-C.
** The supported connector type is "male-female".
Cable Substitution
The test port cables specified for the E5071C have been characterized for
connector repeatability, magnitude and phase stability with flexing, return
loss, insertion loss, and aging rate. Since test port cable performance is a
significant contributor to the system performance, cables of lower
performance will increase the uncertainty of your measurement. It is highly
recommended that the test port cables be regularly tested.
If the system verification is performed with a non-Agilent cable, ensure
that the cable meets or exceeds the operation of the specified cable.
Cable Flex Factor
