E5071C
918
Interpolatin
g the
calibration
coefficient
On/Off setting is
definable.
Always On.
Defining
the
calibration
kit
Calibration
class
• S11A
(OPEN)
• S11B
(SHORT)
• S11C
(LOAD)
• S22A
(OPEN)
• S22B
(SHORT)
• S22C
(LOAD)
• Forward
Transmissio
n
• Forward
Match
• Reverse
Transmissio
n
• Reverse
Match
• Response
•
Response &
Isolation
• TRL Thru
• TRL Reflect
• TRL
Line/Match
• OPEN
• SHORT
• LOAD
• THRU
(OPEN,
SHORT, and
LOAD are
set for each
port; THRU
is set
between
ports)
• TRL Thru
• TRL Reflect
• TRL
Line/Match
Class
indication
label
Editable Editable
