Agilent Technologies E5071C - Page 703

E5071C
930
• real
• imaginary
Test port
output
Number of
ports
• 2 ports
• 2 and 4
port
options
are
available
Frequency
•
30 kHz to
3 GHz
(Std.)
•
30 kHz to
6 GHz
(Opt.
006)
The following
frequency
range is
available
depending on
the option.
• 9 kHz to
4.5/6.5/8
.5 GHz
• 100 kHz
to
4.5/6.5/8
.5 GHz
• 300 kHz
to 14/20
GHz
Power level
• -85 to
+10 dBm
(Std.)
• -
85 to +8
dBm
(Opts.
014/075)
• -
55 to 10
dBm
Characteristic
Impedance
• 50 ohm
(Std.)
• 75 ohm
(Opt.
075)
• 50 ohm
Coupled/Unco
upled power
levels
You can define
Couple/Uncoupl
e between
Traces are
coupled on the
same channel,
