E5071C
996
To turn on/off the stimulus signal output, use the following commands. For
example, if the power output is automatically turned off due to the power
trip feature, remove the cause of the over-input and turn on the stimulus
signal output by executing the following command. You cannot perform
measurement until you turn on the stimulus signal output.
:OUTP
Configuring linear/log sweep settings
To set the sweep range, use the following commands:
Type Command
Start value
:SENS{1-36}:FREQ:STAR
Stop value
:SENS{1-36}:FREQ:STOP
Center value
:SENS{1-36}:FREQ:CENT
Span value
:SENS{1-36}:FREQ:SPAN
To set the number of measurement points, use the following command:
:SENS{1-36}:SWE:POIN
To set the sweep time, use the following commands:
Type Command
Sweep time
:SENS{1-36}:SWE:TIME
Turning on/off auto setting
:SENS{1-36}:SWE:TIME:AUTO
To set the sweep delay time, use the following command:
:SENS{1-36}:SWE:DEL
To set the IF bandwidth, use the one of the following commands (both
provide the same function):
:SENS{1-36}:BAND
:SENS{1-36}:BWID
Setting power level
To set the power level, use the following command:
:SOUR{1-36}:POW
To select whether to output the same power level (the set value for port 1)
or a different power level for each port, use the following command:
