Programming
1035
• :ABOR
• *RST
When the trigger system is in "Hold" state and one of the channels
switches to "Initiate" state (arrow "f" in the above figure), the trigger
system switches to "Waiting for Trigger" state (arrow "a" in the above
figure).
"Waiting for Trigger" State
When the trigger system is in "Waiting for Trigger" state and either the
instrument is triggered (i.e., a trigger is detected) or one of the following
commands is executed, the trigger system switches to "Measurement"
state (arrow "b" in the above figure)
• :TRIG
• :TRIG:SING
As shown in the table below, the instrument is triggered differently
depending on which trigger source is specified. To specify the trigger
source, use the :TRIG:SOUR command.
Trigger
Source
How instrument is
triggered
Internal
trigger
The instrument is
automatically triggered
within itself.
External
trigger
The instrument is
triggered when a
trigger signal is input
through the Ext Trig
terminal or the handler
interface
Bus
trigger
The instrument is
triggered when the
*TRG command is
issued.
Manual
trigger
The instrument is
triggered when you
press Trigger > Trigger
on the front panel.
"Measurement" State
To Next Page
