Programming
1095
negative pulse. A
command can be available
for altering the Low/High
level logic.
4 /OUTPUT2 Output
Changes to the Low level
when /INPUT1 receives a
negative pulse.A command
can be available for
altering the Low/High level
logic.
5 /PORT A0 Output
Bit 0 of port A (8 bit
parallel output port)
6 /PORT A1 Output Bit 1 of port A.
7 /PORT A2 Output Bit 2 of port A.
8 /PORT A3 Output Bit 3 of port A.
9 /PORT A4 Output Bit 4 of port A.
10 /PORT A5 Output Bit 5 of port A.
11 /PORT A6 Output Bit 6 of port A.
12 /PORT A7 Output Bit 7 of port A.
13 /PORT B0 Output
Bit 0 of port B (8 bit
parallel output port)
14 /PORT B1 Output Bit 1 of port B.
15 /PORT B2 Output Bit 2 of port B.
16 /PORT B3 Output Bit 3 of port B.
17 /PORT B4 Output Bit 4 of port B.
18
/EXTERNAL
TRIGGER
Input
An external trigger signal.
When the trigger source is
set to the "External," this
port generates a trigger in
respond to the trailing
edge of a negative pulse.
To Next Page
