Agilent Technologies E5071C User Manual

E5071C
1150
Bit
Position
Name Description
0
Trace 15, 16 Ripple Test
summary (questionable
ripple limit channel {1-
16} extra status register
summary)
Set to "1" while one of the
enabled bits in the
questionable ripple limit
channel {1-16} extra status
event register is set to "1."
1 Trace 1 Ripple Test Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
ripple test result for trace 1.
2 Trace 2 Ripple Test Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
ripple test result for trace 2.
3 Trace 3 Ripple Test Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
ripple test result for trace 3.
4 Trace 4 Ripple Test Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
ripple test result for trace 4.
5 Trace 5 Ripple Test Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
ripple test result for trace 5.
