80 Chapter 2
Agilent VEE Programming Techniques
General Techniques
1. Open the program (simple-program.vee) you created in “Adding an
Amplitude Input and Real64 Slider” on page 71. The program should
appear in the main work area.
2. Remove the
Real64 Slider from the program. (It is not used in this
exercise.) Click to open the
Real64 Slider Object Menu, and select
Cut, or double-click on the Real64 Slider Object Menu button.
Note If you run the program again now, with the Real64 Slider object
removed and the input pin still on the
Noise Generator, you will get a
VEE error message that the input pin
Amplitude on the Noise
Generator
is not connected. Remember, all input pins must be connected
for a VEE program to run.
3. In the
Noise Generator object, click the Object Menu button or
click the right button over the object to open the object menu. Select
Delete Terminal ⇒ Input, and in the dialog box for Choose an
input to delete
with Amplitude highlighted, click OK.
4. Rename the program by choosing
File ⇒ Save As... and type in the
new name
usrobj-program1.vee.
5. Then, minimize the
Noise Generator object and rearrange the objects
as shown Figure 2-2.
