Chapter 4 201
Analyzing and Displaying Test Data
Chapter Checklist
Chapter Checklist
You should now be able to do the following tasks. Review topics as needed,
before going on to the next chapter.
n Describe the main data types in VEE.
n Describe some of the main areas of analytical capabilities in VEE.
n Find an online
Help explanation for any object in the Function &
Browser
dialog box.
n Describe the relationship between input pins and variables in a VEE math
object.
n Evaluate a mathematical expression using the
Formula object, and then
evaluate two expressions using the
Formula object. (Remember to use a
semicolon after the first line.)
n Use a VEE function in a mathematical expression in the Formula object.
n Use the MATLAB Script object.
n Describe major display capabilities in VEE.
n Customize a graphical display in terms of the scales used, the part of the
waveform seen, the markers used, and the color of the trace.
