Glossary 537
Selection Field
A field in an object or dialog box that allows you to select choices from a
drop-down list.
Sequence Input Pin
The top pin of an object. When connected, execution of the object is held
off until the pin receives a container (is “pinged”).
Sequence Output Pin
The bottom pin of an object. When connected, this output pin is activated
when the object and all data propagation from that object finishes
executing.
Status bar
A line at the bottom of the VEE window in which information about the
current status of and information about VEE is displayed.
Status field
A field displaying information that cannot be edited. A status field looks
like an entry field, but has a gray background.
Terminal
The internal representation of a pin that displays information about the
pin and the data container held by the pin. Double-click a terminal to
view the container information.
Title Bar
The rectangular bar at the top of the open view of an object or window,
which shows the title of the object or window. You can turn off an object
title bar using
Properties in the object menu.
Toolbar
The rectangular bar at the top of the VEE window which provides
buttons for quick access to frequently used commands. The buttons run
commands from menus such as
File, Edit, View, Device, and Debug.
