12. Controller Operation
Capture Still
Image 12-26
With the Capture Still B utton a S till Store can be captured via syntax. T he Source File num bers input will capture.
Syntax:
SOURCE # Capture Still
As a Direct select function it does not require ENTER in the end
Barco Eye
Image 12-27
The Barco Eye button works as a Modie r Button, like W indows/CTRL/Fn button on a key board. This is further described in func-
tionality around other buttons.
Mod PGM (Modify Program) [Red button cap]
Image 12-28
Pressing bu tton Unlocks Selected De stinations Program for Edit just as clicking the small lock in Program.
Red LE D indicates active.
Live [Red button cap]
Image 12-29
The Live button latches and Red LED indicates active.
When the live function is active the Assign Key Source BUS or the Syntax actions regarding LAYER S/SOURCE /PRES ET/USE R
KEY are applied in the PRO G RA M as opp osed to the no
rmal PREVIEW B US.
LAYER
Layer Selection is mad e on P ROG RAM.
SOURCE
Actions on layer SOURCE ONLY are executed on Pr ogram.
PRESET
Presets recalled with syntax and As sign Button are applied in Preview and transition direct t o Program.
USER KEY
Userkeys recalled with syntax and Assign Button are applied direc t in Program.
T-Bar Disable
Image 12-30
346 R5905948 EVENT MASTER DEVICES 17/07/2017
