Cisco Catalyst 4500 Series Command Reference Guide

2-1075
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
switchport vlan mapping
Note You cannot configure one-to-one mapping and selective QinQ on the same interface.
The no form of the switchport vlan mapping commands clears the specified mapping configuration.
The no switchport vlan mapping all command clears all mapping configurations on the interface.
You cannot configure encapsulation replicate on a SPAN destination port if the source port is configured
as a tunnel port or has a 1-to-2 mapping configured. Encapsulation replicate is supported with 1-to-1
VLAN mapping.
Examples This example shows how to use one-to-one mapping to map VLAN IDs 1 and 2 in the customer network
to VLANs 1001 and 1002 in the service-provider network and to drop traffic from any other VLAN IDs.
Switch(config)# interface gigabiethernet0/1
Switch(config-if)# switchport vlan mapping 1 1001
Switch(config-if)# switchport vlan mapping 2 1002
Switch(config-if)# exit
This example shows how to configure selective QinQ mapping on the port so that traffic with a C-VLAN
ID of 5, 7, or 8 would enter the switch with an S-VLAN ID of 100. The traffic of any other VLAN IDs
is dropped.
Switch(config)# interface gigabiethernet0/1
Switch(config-if)# switchport vlan mapping 5, 7-8 dot1q-tunnel 100
Switch(config-if)# exit
Related Commands Command Description
show vlan mapping Displays VLAN mapping information.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
