Cisco Catalyst 4500 Series Command Reference Guide

2-669
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
show diagnostic result module
show diagnostic result module
To display the module-based diagnostic test results, use the show diagnostic result module command.
show diagnostic result module [slot-num | all] [test [test-id | test-id-range | all]] [detail]
Syntax Description
Defaults A summary of the test results for all modules in the chassis is displayed.
Command Modes Privileged EXEC mode
Command History
Examples This example shows how to display the summary results for all modules in the chassis:
Switch# show diagnostic result module
Current bootup diagnostic level: minimal
module 1:
Overall diagnostic result: PASS
Diagnostic level at card bootup: bypass
Test results: (. = Pass, F = Fail, U = Untested)
1) supervisor-bootup -----------------------> U
2) packet-memory-bootup --------------------> U
3) packet-memory-ongoing -------------------> U
module 4:
Overall diagnostic result: PASS
Diagnostic level at card bootup: minimal
Test results: (. = Pass, F = Fail, U = Untested)
1) linecard-online-diag --------------------> .
slot-num (Optional) Specifies the slot on which diagnostics are displayed.
all (Optional) Displays the diagnostics for all slots.
test (Optional) Displays selected tests on the specified module.
test-id (Optional) Specifies a single test ID.
test-id-range (Optional) Specifies a range of test IDs.
all (Optional) Displays the diagnostics for all tests.
detail (Optional) Displays the complete test results.
Release Modification
12.2(18)EW Support for this command was introduced on the Catalyst 4500 series switch.
