Cisco Catalyst 4500 Series Command Reference Guide

2-543
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
power redundancy combined max inputs
power redundancy combined max inputs
To configure the power settings for the chassis specifically for 'Combined Mode Resiliency', use the
power redundancy combined max inputs command. To return to the default setting, use the default
form of this command.
Note This feature only applies in combined mode when both power supply bays contain the 4200 W AC, 6000
W AC, or 9000W power supply.
power redundancy combined max inputs {x | y}
default power redundancy combined max inputs
Syntax Description
Defaults Redundant power management mode
Command Modes Global configuration mode
Command History
Usage Guidelines Using the combined mode power resiliency feature, you can limit the power usage to a maximum of two
or three (configurable) inputs for 4000W and 6000W power supplies. For 9000W power supplies, you
can limit the power usage to a maximum of 2 to 5 inputs, since the 9000W is a triple input power supply.
With two 4200 W AC or 6000 W AC power supplies, a maximum of four inputs are available. With two
9000W, a maximum of six inputs are available. This feature allows you to cap the power usage to that of
two/three inputs or four/five inputs. If one of the power supplies fails, no loss of power occurs because
you have capped its usage to a smaller number of inputs.
If you have max inputs 3 configured with four "good" (220 V) inputs and you limit the user to 5500 W
instead of 7600 W and one subunit fails or is powered off, you have three quality inputs providing 5500
W and the chassis is powered at the same rate as it was prior to the failure event:
Switch# configuration terminal
x | y Sets the max input limits.
If 9000W power supplies are installed, the valid input range is 2-5.
Note The maximum number of power-supply inputs with two 9000W power
supplies is 6.
If 4200W or 6000W power supplies are installed, the valid input range is 2-3.
Note The maximum number of power-supply inputs with either two 4200W or
two 6000W power supplies is 4.
Release Modification
IOS XE 3.4.0SG
and 15.1(2)SG
Support for this command was introduced on the Catalyst 4500 series switch.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
