Cisco Catalyst 4500 Series Command Reference Guide

2-1085
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
traceroute mac ip
traceroute mac ip
To display the Layer 2 path that is taken by the packets from the specified source IP address or hostname
to the specified destination IP address or hostname, use the traceroute mac command.
traceroute mac ip {source-ip-address | source-hostname} {destination-ip-address |
destination-hostname} [detail]
Syntax Description
Defaults This command has no default settings.
Command Modes Privileged EXEC mode
Command History
Usage Guidelines The Layer 2 traceroute feature is available on these switches:
• Catalyst 2950 switches running Release 12.1(12c)EA1 or later
• Catalyst 3550 switches running Release 12.1(12c)EA1 or later
• Catalyst 4500 series switches running Catalyst operating system Release 6.2 or later for the
supervisor engine
• Catalyst 4500 series switches running Release 12.1(15)EW or later
• Catalyst 5000 family switches running Catalyst operating system Release 6.1 or later for the
supervisor engine
• Catalyst 6500 series switches running Catalyst operating system Release 6.1 or later for the
supervisor engine
For Layer 2 traceroute to functional properly, Cisco Discovery Protocol (CDP) must be enabled on all
the switches in the network. Do not disable CDP.
When the switch detects a device in the Layer 2 path that does not support Layer 2 traceroute, the switch
continues to send Layer 2 trace queries and lets them time out.
The maximum number of hops identified in the path is ten.
source-ip-address IP address of the source switch as a 32-bit quantity in dotted-decimal
format.
destination-ip-address IP address of the destination switch as a 32-bit quantity in dotted-decimal
format.
source-hostname IP hostname of the source switch.
destination-hostname IP hostname of the destination switch.
detail (Optional) Displays detailed traceroute MAC IP information.
Release Modification
12.1(13)EW Support for this command was introduced on the Catalyst 4500 series switch.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
