Cisco Catalyst 4500 Series Command Reference Guide

2-424
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
macro apply cisco-desktop
macro apply cisco-desktop
To enable the Cisco-recommended features and settings that are suitable for connecting a switch port to
a standard desktop, use the macro apply cisco-desktop command.
macro apply cisco-desktop $AVID access_vlanid
Syntax Description
Defaults This command has no default settings.
Command Modes Interface configuration mode
Command History
Usage Guidelines This command can only be viewed and applied; it cannot be modified.
Ensure that the existing configuration on the interface does not conflict with the intended macro
configuration. Before you apply the macro, clear the configuration on the interface with the default
interface command.
Examples This example shows how to enable the Cisco-recommended features and settings on port fa2/1:
Switch(config)# interface FastEthernet2/1
Switch(config-if)# macro apply cisco-desktop $AVID 50
Switch(config-if)#
The contents of this macro are as follows:
# Basic interface - Enable data VLAN only
# Recommended value for access vlan (AVID) should not be 1
switchport access vlan $AVID [access_vlanid]
switchport mode access
# Enable port security limiting port to a single
# MAC address -- that of desktop
switchport port-security
# Ensure port-security age is greater than one minute
# and use inactivity timer
# “Port-security maximum 1” is the default and will not
# Show up in the config
switchport port-security violation restrict
switchport port-security aging time 2
switchport port-security aging type inactivity
# Configure port as an edge network port
spanning-tree portfast
spanning-tree bpduguard enable
$AVID access_vlanid Specifies an access VLAN ID.
Release Modification
12.2(18)EW Support for this command was introduced on the Catalyst 4500 series switch.
