Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
macro apply cisco-router
macro apply cisco-router
To enable the Cisco-recommended features and settings that are suitable for connecting a switch port to
a router, use the macro apply cisco-router command.
macro apply cisco-router $NVID native_vlanid
Syntax Description
Defaults This command has no default settings.
Command Modes Interface configuration mode
Command History
Usage Guidelines This command can only be viewed and applied; it cannot be modified.
Ensure that the existing configuration on the interface does not conflict with the intended macro
configuration. Before you apply the macro apply cisco-router command, clear the configuration on the
interface with the default interface command.
Examples This example shows how to enable the Cisco-recommended features and settings on port fa2/1:
Switch(config)# interface FastEthernet2/1
Switch(config-if)# macro apply cisco-router $NVID 80
Switch(config-if)#
The contents of this macro are as follows:
# Access Uplink to Distribution
switchport trunk encapsulation dot1q
# Define unique Native VLAN on trunk ports
# Recommended value for native vlan (NVID) should not be 1
switchport trunk native vlan $NVID [native_vlan_id]
# Update the allowed VLAN range (VRANGE) such that it
# includes data, voice and native VLANs
# switchport trunk allowed vlan $VRANGE [vlan_range]
# Hardcode trunk and disable negotiation to
# speed up convergence
# Hardcode speed and duplex to router
switchport mode trunk
switchport nonegotiate
speed 100
duplex full
# Configure qos to trust this interface
auto qos voip trust
qos trust dscp
$NVID native_vlanid Specifies a native VLAN ID.
Release Modification
12.2(18)EW Support for this command was introduced on the Catalyst 4500 series switch.
