Cisco Catalyst 4500 Series Command Reference Guide

2-1096
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
tx-queue
tx-queue
To configure the transmit queue parameters for an interface, use the tx-queue command. To return to the
default value, use the no form of this command.
tx-queue [queue-id] {bandwidth bandwidth-rate | priority high | shape shape-rate}
no tx-queue
Syntax Description
Defaults The default settings are as follows:
• Encapsulation type is dependent on the platform or interface hardware.
• QoS enabled bandwidth rate is 4:255.
• QoS disabled bandwidth rate is 255:1.
Command Modes Interface configuration mode
Command History
Usage Guidelines This command is not supported on the Supervisor Engine 6-E and Catalyst 4900M chassis.
The bandwidth and shape rates cannot exceed the maximum speed of the interface.
The bandwidth can be configured only on the following:
• Uplink ports on Supervisor Engine III (WS-X4014)
• Ports on the WS-X4306-GB module
• The two 1000BASE-X ports on the WS-X4232-GB-RJ module
• The first two ports on the WS-X4418-GB module
• The two 1000BASE-X ports on the WS-X4412-2GB-TX module
Only transmit queue 3 can be configured to be a high-priority transmit queue.
queue-id (Optional) Number of the queue; valid values are from 1 to 4.
bandwidth bandwidth-rate Specifies traffic bandwidth; valid values are from 16000 to
1000000000 bits per second.
priority high Specifies high priority.
shape shape-rate Specifies the maximum rate that packets are passed through a
transmit queue; valid values are from 16000 to 1000000000 bits per
second.
Release Modification
12.1(8a)EW Support for this command was introduced on the Catalyst 4500 series switch.
