Cisco Catalyst 4500 Series Command Reference Guide

2-280
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
hw-module uplink select
Examples This example shows how to select the Gigabit Ethernet uplinks:
Switch(config)# hw-module uplink select gigabitethernet
A reload of the active supervisor is required to apply the new configuration.
Switch(config)# exit
Switch#
Note The Gigabit Ethernet uplinks will be active after the next reload.
This example shows how to select the Gigabit Ethernet uplinks in a redundant system in SSO mode:
Switch(config)# hw-module uplink select gigabitethernet
A 'redundancy reload shelf' or power-cycle of chassis is required to apply the new
configuration
Switch(config)# exit
Switch#
Note The Gigabit Ethernet uplinks will be active after the next reload of the chassis/shelf. Use the
redundancy reload shelf command to reload the chassis/shelf.
This example shows how to select the Gigabit Ethernet uplinks in a redundant system in RPR mode:
Switch(config)# hw-module uplink select gigabitethernet
A reload of the active supervisor is required to apply the new configuration.
Switch(config)# exit
Switch#
Note The Gigabit Ethernet uplinks will be active on a switchover or reload of the active supervisor engine.
This example shows how to select all the uplinks in a redundant system in SSO mode:
Switch(config)# hw-module uplink select all
Warning: This configuration mode may disable slot10.
A 'redundancy reload shelf' or power-cycle of chassis is required to apply the new
configuration.
Switch(config)# exit
Switch#
Note If you select the all keyword, only the Drome board will be supported in the tenth slot of the supervisor
engine.
SFP+ — — — SFP — — — 11 Gbps
SFP — — — SFP+ — — — 11 Gbps
SFP — — — SFP — — — 2 Gbps
Choose 1-Gigabit operation through the command line interface.
SFP SFP — — SFP SFP — — 4 Gbps
Table 2-7 Uplink Options for Redundant Supervisor Mode
Active Supervisor Uplink
Ports
Standby Supervisor Uplink
Ports
A1 A2 A3 A4 B1 B2 B3 B4
Speeds Achievable with this
Combination of Pluggables

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
