2-288

Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)

OL-27596 -01

Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches

interface (virtual switch)

Examples The following example shows how to enter the interface configuration mode on the GigabitEthernet

interface for switch 1, module 2, port 4:

Router(config)# interface gigabitethernet 1/2/4

Router(config)#

Related Commands Command Description

show interfaces (virtual switch) Displays the traffic that is seen by a specific interface.
