Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
mac access-list extended
Table 2-11 describes mapping an Ethernet packet to a protocol family.
dest-mac mask (Optional) Specifies a destination MAC address of the form:
dest-mac-address dest-mac-address-mask.
name-coded
ethertype
(Optional) Denotes a predefined name-coded ethertype for common protocols:
aarp—AppleTalk ARP
amber—DEC-Amber
appletalk—AppleTalk/EtherTalk
dec-spanning—DEC-Spanning-Tree
decnet-iv—DECnet Phase IV
diagnostic—DEC-Diagnostic
dsm—DEC-DSM
etype-6000—0x6000
etype-8042—0x8042
lat—DEC-LAT
lavc-sca—DEC-LAVC-SCA
mop-console—DEC-MOP Remote Console
mop-dump—DEC-MOP Dump
msdos—DEC-MSDOS
mumps—DEC-MUMPS
netbios—DEC-NETBIOS
protocol-family An Ethernet protocol family
vines-echo—VINES Echo
vines-ip—VINES IP
xns-idp—XNS IDP
no (Optional) Deletes a statement from an access list.
permit Allows access if the conditions are matched.
protocol-family (Optional) Name of the protocol family. Table 2-11 lists which packets are
mapped to a particular protocol family.
src-mac mask Source MAC address in the form:
source-mac-address source-mac-address-mask.
Table 2-10 mac access-list extended Subcommands (continued)
Subcommand Description
Table 2-11 Mapping an Ethernet Packet to a Protocol Family
Protocol Family Ethertype in Packet Header
Appletalk 0x809B, 0x80F3
Arp-Non-Ipv4 0x0806 and protocol header of Arp is a non-Ip protocol family
Decnet 0x6000-0x6009, 0x8038-0x8042

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
