Cisco Catalyst 4500 Series Command Reference Guide

2-674
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
show diagnostic result module test
Slot Ports Card Type Diag Status Diag Details
---- ----- -------------------------------------- ---------------- ------------
6 48 10/100/1000BaseT (RJ45)V, Cisco/IEEE Passed None
Detailed Status
---------------
. = Pass U = Unknown
L = Loopback failure S = Stub failure
I = Ilc failure P = Port failure
E = SEEPROM failure G = GBIC integrity check failure
Ports 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
. . . . . . . . . . . . . . . .
Ports 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
. . . . . . . . . . . . . . . .
Ports 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
. . . . . . . . . . . . . . . .
___________________________________________________________________________
2) online-diag-tdr:
Port 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
----------------------------------------------------------------------------
. U U U U U U U U U U U U U U U U U U U U U U U
Port 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
----------------------------------------------------------------------------
U U U U U U U U U U U U U U U U U U U U U U U U
Error code --------------------------> 0 (DIAG_SUCCESS)
Total run count ---------------------> 1
Last test execution time ------------> Jan 22 2001 03:01:54
First test failure time -------------> n/a
Last test failure time --------------> n/a
Last test pass time -----------------> Jan 22 2001 03:01:54
Total failure count -----------------> 0
Consecutive failure count -----------> 0
Detailed Status
---------------
TDR test is in progress on interface Gi6/1
___________________________________________________________________________
Switch#
Related Commands Command Description
diagnostic start Runs the specified diagnostic test.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
