EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 242
GCTL_GPIO_SIMPLE
0xE005100C
10.4.2 GCTL_GPIO_SIMPLE (continued)
This register is used to determine if the simple GPIO function should override the (GCTL_IOMATRIX specified) function of
each pin on a per-pin basis. GCTL_GPIO_COMPLEX takes precedence over GCTL_GPIO_SIMPLE.
60:0 OVERRIDE[60:0 When bit <n> is set, the corresponding pin maps to simple GPIO <n>.
GCTL_GPIO_SIMPLE GPIO Override Configuration Register
b7 b6 b5 b4 b3 b2 b1 b0
OVERRIDE[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
R R R R R R R R
0 0 0 0 0 0 0 0
Bit Name Description
