Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 491
LNK_LTSSM_STATE
0xE0033054
10.15.14 LNK_LTSSM_STATE
Link Training Status State Machine (LTSSM) State Register
USB 3.0 interface link layer state control and status
5:0 LTSSM_STATE[5:0] LTSSM State. See USBLNK_LTSSM Tab in USB-RegMap.xls for more details.
LNK_LTSSM_STATE Link Training Status State Machine (LTSSM) State Register 0xE0033054
b31 b30 b29 b28 b27 b26 b25 b24
LNK_LTSSM_STATE Link Training Status State Machine (LTSSM) State Register
b23 b22 b21 b20 b19 b18 b17 b16
LNK_LTSSM_STATE Link Training Status State Machine (LTSSM) State Register
b15 b14 b13 b12 b11 b10 b9 b8
LNK_LTSSM_STATE Link Training Status State Machine (LTSSM) State Register
b7 b6 b5 b4 b3 b2 b1 b0
LTSSM_STATE[5:0]
RRRRRR
R/W R/W R/W R/W R/W R/W
000000
Bit Name Description
