EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 520
PROT_EPI_UNMAPPED_STREAM
0xE0033580
10.16.13 PROT_EPI_UNMAPPED_STREAM
Unmapped Stream Request Register
There are 16 PROT_EPI_UNMAPPED_STREAM registers. The address of each is calculated as PROT_EPI_UN-
MAPPED_STREAM(x) = 0xE0033580 + (x*0x4). Hence PROT_EPI_UNMAPPED_STREAM(0) is at address 0xE0033580,
PROT_EPI_UNMAPPED_STREAM(1) is at address 0xE0033580 + 0x4 and so on. The definition of each of these is the same.
A register for each Endpoint to handle a request for a StreamID that is not currently mapped to a socket.
19:16 SPSM_STATE[3:0] Stream Protocol State Machine (SPSM) State for this EndPoint:
0 Not Configured
1Disabled
2Prime Pipe
3 DFR Prime Pipe
4Idle
5 Start Stream
6 Move Data
7End
8Error
15:0 STREAM_ID[15:0] The StreamID of the current stream activated (or requested to be activated) by the protocol layer.
PROT_EPI_UNMAPPED_STREAM Unmapped Stream Request 0xE0033580
b31 b30 b29 b28 b27 b26 b25 b24
PROT_EPI_UNMAPPED_STREAM Unmapped Stream Request
b23 b22 b21 b20 b19 b18 b17 b16
SPSM_STATE[3:0]
RRRR
R/W R/W R/W R/W
0000
PROT_EPI_UNMAPPED_STREAM Unmapped Stream Request
b15 b14 b13 b12 b11 b10 b9 b8
STREAM_ID[15:8]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
PROT_EPI_UNMAPPED_STREAM Unmapped Stream Request
b7 b6 b5 b4 b3 b2 b1 b0
STREAM_ID[7:0]
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
Bit Name Description
