Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 325
GPIF_STATE_COUNT_CONFIG
0xE001408C
10.7.19 GPIF_STATE_COUNT_CONFIG
State Counter Configuration Register
Configures the first 16-bit state counter.
1 SW_RESET 0 Hardware write 0 to signal that counter has reset
1 Software writes one to reset/load the counter
0 ENABLE 0 This counter is not used.
1 This counter is used.
GPIF_STATE_COUNT_CONFIG State Counter Configuration Register 0xE001408C
b31 b30 b29 b28 b27 b26 b25 b24
GPIF_STATE_COUNT_CONFIG State Counter Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
GPIF_STATE_COUNT_CONFIG State Counter Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
GPIF_STATE_COUNT_CONFIG State Counter Configuration Register
b7 b6 b5 b4 b3 b2 b1 b0
SW_RESET ENABLE
R/W1S R/W
R/W0C R
00
Bit Name Description
