EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 415
OTG_INTR
0xE0031810
10.12.5 OTG_INTR
OTG Interrupt Register
5 OTG_TIMER_TIMEOUT OTG Timer Timeout Interrupt
The OTG Timer has reached its terminal count of 0.
4 SRP_VBUS_INT VBUS SRP Interrupt
A B-Device initiated SRP by pulsing the VBUS line.
3SRP_DP_INT D+ SRP Interrupt
A B-Device initiated SRP by pulsing the D+ signal.
2 B_END_SESS_INT B_END_SESS Interrupt
Set when B_END_SESS goes active
1 B_SESS_VALID_INT B_SESS_VALID Change Interrupt
Set when B_SESS_VALID changes.
0 A_SESS_VALID_INT A_SESS_VALID Change Interrupt
Set when A_SESS_VALID changes.
OTG_INTR OTG Interrupt Register 0xE0031810
b31 b30 b29 b28 b27 b26 b25 b24
OTG_INTR OTG Interrupt Register
b23 b22 b21 b20 b19 b18 b17 b16
OTG_INTR OTG Interrupt Register
b15 b14 b13 b12 b11 b10 b9 b8
OTG_INTR OTG Interrupt Register
b7 b6 b5 b4 b3 b2 b1 b0
OTG_TIMER_
TIMEOUT
SRP_VBUS_INT SRP_DP_INT
B_END_SESS_
INT
B_SESS_VALID_I
NT
A_SESS_VALID_
INT
R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C
R/W1S R/W1S R/W1S R/W1S R/W1S R/W1S
000000
Bit Name Description
