EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 404
DEV_EPO_XFER_CNT
0xE00314D8
10.11.9 DEV_EPO_XFER_CNT
OUT Endpoint Remaining Transfer Length Register
There are 16 DEV_EPO_XFER_CNT registers. The address of each is calculated as DEV_EPO_XFER_CNT(x) = 0xE-
00314D8 + (x*0x4). Hence DEV_EPO_XFER_CNT(0) is at address 0xE00314D8, DEV_EPO_XFER_CNT(1) is at address
0xE00314D8 + 0x4 and so on. The definition of each of these is the same.
This register counts down the remaining bytes left in the transfer.
23:0 BYTES_REMAINING[23:0] Number of bytes remaining in the transfer. This value will never go negative (if more bytes are trans-
ferred than remaining in counter, counter value stays at 0).
DEV_EPO_XFER_CNT OUT Endpoint Remaining Transfer Length Register 0xE00314D8
b31 b30 b29 b28 b27 b26 b25 b24
DEV_EPO_XFER_CNT OUT Endpoint Remaining Transfer Length Register
b23 b22 b21 b20 b19 b18 b17 b16
BYTES_REMAINING[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
DEV_EPO_XFER_CNT OUT Endpoint Remaining Transfer Length Register
b15 b14 b13 b12 b11 b10 b9 b8
BYTES_REMAINING[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
DEV_EPO_XFER_CNT OUT Endpoint Remaining Transfer Length Register
b7 b6 b5 b4 b3 b2 b1 b0
BYTES_REMAINING[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
