EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 486
LNK_PHY_ERROR_CONF
0xE0033040
10.15.11 LNK_PHY_ERROR_CONF
PHY Error Counter Configuration Register
From RxStatus[2:0] [PIPE, p 22]
Configuration of receive error counter for the USB 3.0 PHY errors. This is for debug purposes.
8 PHY_LOCK_EN Enable Counting of PHY Lock Loss. Lock Indicator To Be Determined
7 TRAINING_ERROR_EN Enable Counting of Training Sequence Error
6 RX_ERROR_CRC32_EN Enable Counting of Receive CRC-32 Error
5 RX_ERROR_CRC16_EN Enable Counting of Receive CRC-16 Error
4 RX_ERROR_CRC5_EN Enable Counting of Receive CRC-5 Error
3 PHY_ERROR_DISPARITY_EN Enable Counting of Receive Disparity Error (RxStatus == 3'b111)
2 PHY_ERROR_EB_UND_EN Enable Counting of Elastic Buffer Underflow (RxStatus == 3'b110)
1 PHY_ERROR_EB_OVR_EN Enable Counting of Elastic Buffer Overflow (RxStatus == 3'b101)
0 PHY_ERROR_DECODE_EN Enable Counting of 8b/10b Decode Errors (RxStatus == 3'b100)
LNK_PHY_ERROR_CONF PHY Error Counter Configuration Register 0xE0033040
b31 b30 b29 b28 b27 b26 b25 b24
LNK_PHY_ERROR_CONF PHY Error Counter Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
LNK_PHY_ERROR_CONF PHY Error Counter Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
PHY_LOCK_EN
R/W
R
1
LNK_PHY_ERROR_CONF PHY Error Counter Configuration Register
b7 b6 b5 b4 b3 b2 b1 b0
TRAINING_
ERROR_EN
RX_ERROR_
CRC32_EN
RX_ERROR_
CRC16_EN
RX_ERROR_
CRC5_EN
PHY_ERROR_DIS
PARITY_EN
PHY_ERROR_EB
_UND_EN
PHY_ERROR_EB
_OVR_EN
PHY_ERROR_DE
CODE_EN
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
11111111
Bit Name Description
