EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 495
LNK_COMPLIANCE_PATTERN_2
0xE0033140
10.15.18 LNK_COMPLIANCE_PATTERN_2
Compliance Pattern CP2 Register
USB 3.0 PHY configuration values for compliance pattern 2.
12 TXONESZEROS Enable TXONESZEROS (PIPE PHY Transmit Signal)
11 LFPS LFPS On/Off
10 DEEMPHASIS De-emphasis On/Off
9 SCRAMBLED Scramble On/Off
8K_D Symbol Type
0 Data (D)
1Symbol (K)
7:0 CP[7:0] Compliance Pattern
LNK_COMPLIANCE_PATTERN_2 Compliance Pattern CP2 Register 0xE0033140
b31 b30 b29 b28 b27 b26 b25 b24
LNK_COMPLIANCE_PATTERN_2 Compliance Pattern CP2 Register
b23 b22 b21 b20 b19 b18 b17 b16
LNK_COMPLIANCE_PATTERN_2 Compliance Pattern CP2 Register
b15 b14 b13 b12 b11 b10 b9 b8
TXONESZEROS LFPS DEEMPHASIS SCRAMBLED K_D
R/W R/W R/W R/W R/W
RRRRR
00100
LNK_COMPLIANCE_PATTERN_2 Compliance Pattern CP2 Register
b7 b6 b5 b4 b3 b2 b1 b0
CP[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
0x78
Bit Name Description
