EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 462
SHDL_INTERNAL_STATUS
0xE0032084
10.14.33 SHDL_INTERNAL_STATUS
Scheduler Internal Status Register
17 TP_EPM_OVERRUN TP EPM over-run
16 TP_EPM_UNDERRUN TP EPM under-run
15 TP_TIMEOUT TP timeout
14 TP_PID_ERROR TP PID error
13 TP_BABBLE TP Babble
12 TP_PORT_ERROR TP Port error
11 TP_PHY_ERROR TP PHY rxerror
10 TP_CRC16_ERROR TP CRC16 Error
9TP_DT_MISMATCHTP DT mismatch
continued on next page
SHDL_INTERNAL_STATUS Scheduler Internal Status Register 0xE0032084
b31 b30 b29 b28 b27 b26 b25 b24
SHDL_INTERNAL_STATUS Scheduler Internal Status Register
b23 b22 b21 b20 b19 b18 b17 b16
TP_EPM_
OVERRUN
TP_EPM_
UNDERRUN
RR
R/W R/W
00
SHDL_INTERNAL_STATUS Scheduler Internal Status Register
b15 b14 b13 b12 b11 b10 b9 b8
TP_TIMEOUT TP_PID_ERROR TP_BABBLE TP_PORT_ERROR TP_PHY_ERROR
TP_CRC16_
ERROR
TP_DT_
MISMATCH
TP_STALL
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000000
SHDL_INTERNAL_STATUS Scheduler Internal Status Register
b7 b6 b5 b4 b3 b2 b1 b0
TP_NYET TP_NAK TP_ACK EP0_IN EP0_OUT EP0_SETUP FRAME_FIT EP_DONE
RRRRRRRR
R/W R/W R/W R/W R/W R/W R/W R/W
00000001
Bit Name Description
