GCTL_IOPOWER_INTR
0xE0051034
10.4.8 GCTL_IOPOWER_INTR
I/O Power Change Interrupt Register
This register generates an interrupt when an interface power domain is powered up or down. Note that a power domain that
is already up when the device resets (including wakeup from standby) also causes an interrupt in this register (which is not
seen by the CPU until the corresponding mask bit is set).
13 USB_POWER_GOOD Interrupt request. Must be cleared by firmware.
12 VBUS_TH Interrupt request. Must be cleared by firmware.
11 VBAT Interrupt request. Must be cleared by firmware.
10 VBUS Interrupt request. Must be cleared by firmware.
9 USB25REG Interrupt request. Must be cleared by firmware.
8 USB33REG Interrupt request. Must be cleared by firmware.
7VIO5 Interrupt request. Must be cleared by firmware.
continued on next page
GCTL_IOPOWER_INTR I/O Power Change Interrupt Register 0xE0051034
b31 b30 b29 b28 b27 b26 b25 b24
GCTL_IOPOWER_INTR I/O Power Change Interrupt Register
b23 b22 b21 b20 b19 b18 b17 b16
GCTL_IOPOWER_INTR I/O Power Change Interrupt Register
b15 b14 b13 b12 b11 b10 b9 b8
USB_POWER_
GOOD
VBUS_TH VBAT VBUS USB25REG USB33REG
R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C
W1S W1S W1S W1S W1S W1S
0 0 0 0 0 0
GCTL_IOPOWER_INTR I/O Power Change Interrupt Register
b7 b6 b5 b4 b3 b2 b1 b0
VIO5 CVDDQ EFVDDQ VIO4 VIO3 VIO2 VIO1
R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C
W1S W1S W1S W1S W1S W1S W1S
0 0 0 0 0 0 0
Bit Name Description
