EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 327
GPIF_DATA_COUNT_CONFIG
0xE0014094
10.7.21 GPIF_DATA_COUNT_CONFIG
Data Counter Configuration Register
Configures the 32-bit data counter.
7:0 INCREMENT[7:0] 8-bit quantity to be added/subtracted to the counter on each clock
3 DOWN_UP 0 Down count
1 Up count
2 SW_RESET 0 Hardware write 0 to signal that counter has reset
1 Software writes one to reset/load the counter
1RELOAD 0 Saturate on reaching the limit
1 Reload on reaching the limit
0 ENABLE 0 This counter is not used.
1 This counter is used.
GPIF_DATA_COUNT_CONFIG Data Counter Configuration Register 0xE0014094
b31 b30 b29 b28 b27 b26 b25 b24
GPIF_DATA_COUNT_CONFIG Data Counter Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
GPIF_DATA_COUNT_CONFIG Data Counter Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
INCREMENT[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
1
GPIF_DATA_COUNT_CONFIG Data Counter Configuration Register
b7 b6 b5 b4 b3 b2 b1 b0
DOWN_UP SW_RESET RELOAD ENABLE
R/W R/W1S R/W R/W
RR/W0CR R
1010
Bit Name Description
