EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 338
GPIF_EGRESS_DATA
0xE00140CC
10.7.32 GPIF_EGRESS_DATA
Socket Egress Data Register
There are four GPIF_EGRESS_DATA registers. The address of each is calculated as GPIF_EGRESS_DATA(x) = 0xE-
00140CC + (x*0x4). Hence GPIF_EGRESS_DATA(0) is at address 0xE00140CC, GPIF_EGRESS_DATA(1) is at address
0xE00140CC + 0x4 and so on. The definition of each of these is the same.
Holds egress data for the active socket in a thread.
31:0 DATA[31:0] Egress data. This register will hold only one word of GPIF_BUS_CONFIG.BUS_WIDTH. No packing/
unpacking is done. MSBs are ignored.
GPIF_EGRESS_DATA Socket Egress Data Register 0xE00140CC
b31 b30 b29 b28 b27 b26 b25 b24
DATA[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_EGRESS_DATA Socket Egress Data Register
b23 b22 b21 b20 b19 b18 b17 b16
DATA[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_EGRESS_DATA Socket Egress Data Register
b15 b14 b13 b12 b11 b10 b9 b8
DATA[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_EGRESS_DATA Socket Egress Data Register
b7 b6 b5 b4 b3 b2 b1 b0
DATA[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
