EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 580
SPI_INTR
0xE0000C08
10.21.3 SPI_INTR
SPI Interrupt Request Register
Interrupt requests. Derived from STATUS register. Interrupt requests must be cleared by CPU and are generated regardless
of values in INTR_MASK register.
6 ERROR Set by hardware when corresponding STATUS asserts, cleared by software.
5TX_HALF Set by hardware when corresponding STATUS asserts, cleared by software.
4 TX_SPACE Set by hardware when corresponding STATUS asserts, cleared by software.
3 TX_DONE Set by hardware when corresponding STATUS asserts, cleared by software.
2 RX_HALF Set by hardware when corresponding STATUS asserts, cleared by software.
1 RX_DATA Set by hardware when corresponding STATUS asserts, cleared by software.
0 RX_DONE Set by hardware when corresponding STATUS asserts, cleared by software.
SPI_INTR SPI Interrupt Request Register 0xE0000C08
b31 b30 b29 b28 b27 b26 b25 b24
SPI_INTR SPI Interrupt Request Register
b23 b22 b21 b20 b19 b18 b17 b16
SPI_INTR SPI Interrupt Request Register
b15 b14 b13 b12 b11 b10 b9 b8
SPI_INTR SPI Interrupt Request Register
b7 b6 b5 b4 b3 b2 b1 b0
ERROR TX_HALF TX_SPACE TX_DONE RX_HALF RX_DATA RX_DONE
R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C R/W1C
R/W1S R/W1S R/W1S R/W1S R/W1S R/W1S R/W1S
0000000
Bit Name Description
