EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 319
GPIF_CTRL_COUNT_CONFIG
0xE0014074
10.7.13 GPIF_CTRL_COUNT_CONFIG
Control Counter Configuration Register
Configures the 16-bit control counter
7:4 CONNECT[3:0] Connect the specified bit of this counter to CTRL[9]
3 SW_RESET 0 Hardware write 0 to signal that counter has reset
1 Software writes one to reset/load the counter
2RELOAD 0 Saturate on reaching the limit
1 Reload on reaching the limit
1 DOWN_UP 0 Down count
1 Up count
0 ENABLE 0 This counter is not used.
1 This counter is used.
GPIF_CTRL_COUNT_CONFIG Control Counter Configuration Register 0xE0014074
b31 b30 b29 b28 b27 b26 b25 b24
GPIF_CTRL_COUNT_CONFIG Control Counter Configuration Register
b23 b22 b21 b20 b19 b18 b17 b16
GPIF_CTRL_COUNT_CONFIG Control Counter Configuration Register
b15 b14 b13 b12 b11 b10 b9 b8
GPIF_CTRL_COUNT_CONFIG Control Counter Configuration Register
b7 b6 b5 b4 b3 b2 b1 b0
CONNECT[3:0 SW_RESET RELOAD DOWN_UP ENABLE
R/W R/W R/W R/W R/W1S R/W R/W R/W
RRRRR/W0CRRR
00000110
Bit Name Description
