EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 560
I2C_SOCKET
0xE0000440
10.19.16 I2C_SOCKET
I
2
C Socket Register
Indicates sockets used for DMA based operation.
15:8 INGRESS_SOCKET[7:0] Socket number for ingress data
0-7 Supported
8-.. Reserved
7:0 EGRESS_SOCKET[7:0] Socket number for egress data
0-7 Supported
8-.. Reserved
I2C_SOCKET I
2
C Socket Register 0xE0000440
b31 b30 b29 b28 b27 b26 b25 b24
I2C_SOCKET I
2
C Socket Register
b23 b22 b21 b20 b19 b18 b17 b16
I2C_SOCKET I
2
C Socket Register
b15 b14 b13 b12 b11 b10 b9 b8
INGRESS_SOCKET[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
I2C_SOCKET I
2
C Socket Register
b7 b6 b5 b4 b3 b2 b1 b0
EGRESS_SOCKET[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
Bit Name Description
