Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 442
OHCI_FM_INTERVAL
0xE003203C
10.14.16 OHCI_FM_INTERVAL
OHCI Frame Control Information Register
31 FIT FrameIntervalToggle
30:16 FSMPS[14:0] FSLargestDataPacket
14:0 FI[14:0] FrameInterval
OHCI_FM_INTERVAL OHCI Frame Control Information Register 0xE003203C
b31 b30 b29 b28 b27 b26 b25 b24
FIT FSMPS[14:8]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
0
OHCI_FM_INTERVAL OHCI Frame Control Information Register
b23 b22 b21 b20 b19 b18 b17 b16
FSMPS[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
0x27F0
OHCI_FM_INTERVAL OHCI Frame Control Information Register
b15 b14 b13 b12 b11 b10 b9 b8
FI[14:8]
R/W R/W R/W R/W R/W R/W R/W
RRRRRRR
OHCI_FM_INTERVAL OHCI Frame Control Information Register
b7 b6 b5 b4 b3 b2 b1 b0
FI[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
0x752F
Bit Name Description
