Cypress EZ-USB FX3 User Manual

EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 376
PP_RD_MAILBOX
0xE0017E4C
10.8.15 PP_RD_MAILBOX
P-Port Read (Egress) Mailbox Registers
continued on next page
PP_RD_MAILBOX P-Port Read (Egress) Mailbox Registers 0xE0017E4C
b63 b62 b61 b60 b59 b58 b57 b56
RD_MAILBOX[63:56]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PP_RD_MAILBOX P-Port Read (Egress) Mailbox Registers
b55 b54 b53 b52 b51 b50 b49 b48
RD_MAILBOX[55:48]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PP_RD_MAILBOX P-Port Read (Egress) Mailbox Registers
b47 b46 b45 b44 b43 b42 b41 b40
RD_MAILBOX[47:40]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PP_RD_MAILBOX P-Port Read (Egress) Mailbox Registers
b39 b38 b37 b36 b35 b34 b33 b32
RD_MAILBOX[39:32]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PP_RD_MAILBOX P-Port Read (Egress) Mailbox Registers
b31 b30 b29 b28 b27 b26 b25 b24
RD_MAILBOX[31:24]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PP_RD_MAILBOX P-Port Read (Egress) Mailbox Registers
b23 b22 b21 b20 b19 b18 b17 b16
RD_MAILBOX[23:16]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
PP_RD_MAILBOX P-Port Read (Egress) Mailbox Registers
b15 b14 b13 b12 b11 b10 b9 b8
RD_MAILBOX[15:8]
R R R R R R R R
R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
